Our galvanized steel strand products have excellent mechanical properties.The vertical hot-dip galvanized technology ensures coating thickness.We employ the most experienced, talented, licensed engineers in the industry to design solutions for your application.
Annual output : 300000 tons per year
Common structure: 7 strands / 19 strands / 37 strands/ 61 strands/ 91 strands/ 127 strands
Application: for ACSR, stay wire, Guy wire, overhead earth wire
Material: high carbon steel
Galvanized steel wire size: Φ1.44mm-4.770mm
Strand size:7×（1.44-4.2 mm）;19×（1.44-3.5mm）;37×（1.44-3.5mm）
Tensile strength: different Grade from min.1470 N/mm2 to min.1960N/mm2
Zinc coating: According to ASTM A475 Class A
Meets ASTM Specifications A475 or A363 or ASTM B498 or BS EN 50189
Excellent Quality With Rich Experience
Shining surface;
Excellent corrosion resistance;
Clean and firm hot-dip zinc coating;
excellent durable anti-fatigue performance;
Professional on Galvanized Strand manufacturing;
Exported to over 40 countries or regions;
Used for mechanical reinforcement in the manufacture of ACSR Cable;
Nominal Diameters and Minimum Weights of Coating for Zinc-Coated Steel Wires
|
Dia(mm) |
1.57 |
1.65 |
1.83 |
2.03 |
2.36 |
2.54 |
2.64 |
2.77 |
3.05 |
3.18 |
3.30 |
3.63 |
3.68 |
3.81 |
4.09 |
4.19 |
4.50 |
4.55 |
|
Zinc Coated(g/m²) |
153 |
153 |
153 |
183 |
214 |
214 |
244 |
244 |
259 |
259 |
259 |
275 |
275 |
275 |
275 |
275 |
275 |
275 |
Raw Material Of Galvanized Steel Strand
Our raw material is high quality carbon steel hot rolled wire rod according to the standard GB/T4354-2008 .
The chemical composition of the steel conforms to the GB/T699-1999 standard.chm
Chemical composition
|
Grade |
Chemical composition table% |
||||
|
|
C |
Si |
Mn |
P |
S |
|
45 |
0.42-0.50 |
0.17-0.37 |
0.5-0.80 |
≦0.035 |
≦0.035 |
|
60 |
0.57-0.65 |
0.17-0.37 |
0.5-0.80 |
≦0.035 |
≦0.035 |
|
65 |
0.62-0.70 |
0.17-0.37 |
0.5-0.80 |
≦0.035 |
≦0.035 |
|
70 |
0.67-0.75 |
0.17-0.37 |
0.5-0.80 |
≦0.035 |
≦0.035 |
|
SWRH77B |
0.74-0.81 |
0.15-0.35 |
0.6-0.90 |
≦0.030 |
≦0.030 |
|
SWRH82B |
0.79-0.86 |
0.15-0.35 |
0.6-0.90 |
≦0.030 |
≦0.030 |
Production Workshop
There are 10 sets of galvanizing production line ,20 complete set of drawing and stranding lines.The produce process of the galvanized steel wire is following as below:
Drawing process:Surface treatment- Drying - Drawing - -Tension Control-winding
Galvanized process:Washing - Drying - Hot Galvanized - Spooling
Stranding process:stranding-Spooling-Inspection-Packing
With comprehensive testing equipment and advanced testing techniques to every processing, we control processing quality timely to ensure all parameters with strict standard to finish qualified products.
