Hoist ropes for floating cranes

Special Steel Wire Ropes for Floating Cranes
Floating cranes are heavy lift vessels specifically designed for the handling of loads within ports, offshore and shipyards. May take the form of a simple Sheerleg arrangement or luffing crane for more complex lifts.

Hoist ropes for floating cranes
35WXEPK7

Rotation resistant wire rope with very high breaking strength
Excellent fatigue properties
Extremely high resistance to flattening and wear.
Particularly suited to multiple layer spooling. A plastic layer between the inner and outer strands protects against inner wear and corrosion of the core.
Rope construction: Rotationally resistant wire rope with compacted inner and outer strands, with a plastic layer between the inner and outer strands.
Marking: according to standard EN 12385-4

40xK7
Rotation resistant, flexible hoist rope made out of compacted outer strands and a compacted steel core
Fully lubricated
Extremely high breaking load
Resistance against drum crushing
Has a core in special design
Hoist rope and boom hoist rope – non rotation resistant

8XK26WS-EPIWRC
Eight-strand rope made out of compacted outer strands
Fully lubricated
Has a plastic layer between the steel core and the outer strands
Has a high breaking load and a good resistance against drum crushing
May not be used with a swivel

10XK26WS-EPIWRC
Ten-strand rope made out of compacted outer strands
Fully lubricated
Has a plastic layer between the steel core and the outer strands, giving the rope a high structural stability, avoiding internal rope destruction and protecting the core against the corrosive environment
High breaking load
Resistance against drum crushing
May not be used with a swivel
Boom Pendants – Non Rotation Resistant

6XK36WS-EPIWRC
Improved bending fatigue performance
Better retention of internal lubrication

10XK26WS
Ten-strand rope in parallel lay construction made out of compacted strands
Fully lubricated
Flexible
Extremely high breaking load

The global success of Aulone’s crane rope is based on an uncompromising commitment to quality. Our wire rope for cranes are designed to provide longer life, less downtime, and superior resistance to bending fatigue for lifting applications under adverse working conditions. Crane ropes supplied by Aulone and its group companies are supported by an extensive global network, offering expert advice to both crane manufacturers and end users.

With 30 decades of excellence in manufacturing specialty steel wire ropes for cranes, we have developed next-generation crane ropes for different applications to meet the specific needs of customers. These cover all types of wire rope for cranes, including specially designed compacted ropes with plastic-impregnated cores and rotation-resistant ropes. All steel wire ropes undergo stringent quality testing procedures. We offer a wide variety of hoist ropes to suit the needs of different industrial applications.

Aulone’s Crane rope finds application in the following areas:

Ship-to-Shore/Quay cranes
Rubber tyre gantry crane
Rail-mounted gantry crane
Mobile harbour cranes
Offshore cranes
Floating cranes
Tower cranes
EOT/Overhead cranes
Crawler cranes
Piling rigs
Truck mounted cranes
Pickup cranes
Size Range:

8 mm to 200 mm

We are happy to help and advise you to provide you with the steel wire rope suiting your crane for optimal performance.
Aulone has a good reputation when it comes to steel wire ropes, working for the worlds leading crane manufacturers.
